| CPUs | ||
| Main CPU | : Z-80 compatible C-MOS CPU | |
| Slave CPU | : 6301 | |
| Sub-CPU | : µPD7508 | |
| Main memory | ||
| RAM | : 64KB | |
| ROM | : 32KB | |
| Memory for slave CPU | ||
| RAM | : 6KB (external) for Video RAM 128 bytes (internal) | |
| ROM | : 4KB (internal) | |
| Display | : LCD display (480 x 64 dots) | |
| Speaker | : Dynamic speaker | |
| Interfaces | : RS-232C, serial, bar code reader, analog input | |
| Keyboard | : ASCII, France, Germany, etc. | |
| Power supply | : NiCd battery pack AC adaptor | |
| Dimensions | : 297(W) x 216(D) x 48(H) mm | |
| Weight | : Approx. 2.3 kg | |
| Environmental conditions | ||
| Temperature | : 5 to 35ºC (operation) - 20 to 60ºC (storage) | |
| Humidity | : 10 to 80% (operation, no condensation) 10 to 80% (storage, no condensation) | |
| Resistance to shock | : Max. 1 G, 1 msec (operation) | |
| Resistance to vibration | : Max. 0.25 G, 55 Hz (operation) | |
G-1
G-2
